DC/DC Converters


You are here:



This line is designed for all non-industrial applications: isolated and non-isolated power supply units/converters, able to supply input-output voltages equal to or different from rated input voltage. Their primary function is to compensate fluctuations in input voltage and maintain a stable output. They can be supplied DIN Rail Mountable or not, all have short-circuit and overload protection on output and guarantee a stable output voltage. Like all Adel system products they comply with the latest standards applied to the industry.

DC/DC Converters
SUP ISO

Key features:

  • Output voltage: 24Vdc
  • Output current: 1.3 plus 10A
  • Adjustable output - 10%
  • "Extremely compact dimensions
  • Temperature range 0 - 50 degrees Celsius

The SUP range includes feeders/converters with galvanic insulation between primary and secondary, based on switching technology, whose input range can range from 18 to 36Vdc, keeping the output voltage stable at 24Vdc, up to 10 A.
Ready for panel fixing, or by accessory, also at DIN Bar. They are protected by short circuit and outbound overhead.


Find out more

» Datasheets and Manuals
DC/DC Converters

SUP

Main features:

  • Input: 12 Vdc
  • Output: 24 - 30 - 40 - 48 - 60 Vdc
  • Output In: 3 A ÷ 6 A
  • Adjustable output ±10%
  • Ambient temperature operation field: 0 - 50° C
  • IP20

The low voltage power supplies/converters in the STEP-UP range are suitable for producing voltages higher than the input voltage. They are typically used for currents of 3-6A, in cases where there is a rated input voltage of 12Vdc transformed into higher output voltage, perhaps to connect to a 12Vdc battery to then power a 24Vdc PLC. STEP-UP units feature switch-mode technology, are DIN Rail Mountable, and have output short-circuit and overload protection. For use in industrial and automotive applications, they are particularly reliable, robust, easy to use and comply with the latest regulatory standards.

Find out more

» Datasheets and Manuals
