Cogeneration, transport, telecommunication, data center, smart grid; the field where you need power also without main for your need power continuity solution. The range of industrial power supplies and CD UBS permit you to monitory the devices also in long distance. Complete range of CD USB and Battery Bank in DIO Rail mount.



Monitor&Control



Monitor, Configure, Connect



The DPY351 is a robust and versatile multifunction display that allows monitoring, configuring and managing the ADELSystem devices connected in an ADELBus network.




  • It is equipped with a high-brightness and wide viewing-angle 3.5’’ TFT screen which guarantees an optimum visibility in any operating condition.

  • Intuitive Human-Machine Interface (HMI) is a user interface or dashboard clear and intuitive
  • Ethernet interface inside, allows to configure and managing true ADELBus the devices connected through its,  by using the SNMP and Modbus TCP protocols.

  • It is possible to connect several devices in chain together, up to 50.



Monitoring
It is possible the monitoring of the input and output data, peak current, peak voltage, all the battery parameters such as temperature, State of Charge internal Impendency

Configuration
With the DPY351, it is possible to modify the parameters of any ADELsystem device connected: DC Ups, Power Supply and Battery Charger.

Alarms management
All the alarms present on the single device are immediately reported.

History
The history parameters are recorded inside each device. The DPY351 allows inspecting all the historical parameters of each single device.

Logging
The device memorize and display the last 20 action done.

Web Server
It is possible configure and drive the device by Own Server

Event
Actions that are coordinated among the devices connected can be programmed, thus automating the system.







So many way to use and apply it


Monitor and Control

To monitor all the parameters of installed devices in the panel

Comunication

Essential to transfer all parameters remotely via Ethernet connection

All in One

It includes 2 Input 1 Output and a temperature sensor that allows sensor management in small environments. All in one: Display, Hub, PLC



Inside



The heart of the easy-to-assemble system is a 90mm hole for all types of surfaces, designed for heavy-duty use in a robust IP67, which allows you to manage multiple units by monitoring, configuring, storing and connecting remotely. A unique device, the first that allows all the functions to be enclosed inside for maximum performance at the highest levels of ADELSystem devices.







Display parameters as you prefer





Display Configuration


Display Configuration “Homepage”




Customize Dashboard







Customize “Six Values”

Customize “Six Values”

Customize “Two Values”

Customize “Single Value"


Add new device

Notification Alarm





Gateway and Protocolli

Web Server HTTP for Configuration and Driver the device by Ethernet; static or Dynamic IP

Modbus TCP/IP Configuration TCP/IP Configuration group of parameter default values. They allow unique identification of the unit in the network.

SNMP v2c An ADELsystem MIB table is provided which consists of a list of parameters of the connected power device that can be remotely read, or read-written through the SNMP. Each parameter, (OID), is mapped one-to-one to a Modbus RTU holding register.

MQTTMQTT communication allows the DPY351 to connect to the ADELView System Cloud for the remote monitoring of the power devices connected to the DPY using Modbus or CANbus



Connection & Control

DPY351 was developed to connect to all the new devices developed by ADELSystem. Through ADELBus (CANBus and ModBus) it is possible to establish the connection of configuration, reading, evolution of the device data. Through the DPY351 it is possible to create Events, they are the result of an algorithm established by the DPY351 among the various interconnected devices.








Interactive functions

Opens the head to ADELSystem devices. View, control, integrate PLC functions and transmit all system functions via Ethernet. Compact, UserFrendly, high performance, it's the device you never thought, but now that it's there and you will not be able to do without it.



» Datasheets and Manuals Scarica File Allegati
DC-UPS




Main features

  • Output current 2,5 A ÷ 20 A even in case of power outage (shortage)
  • Automatic allocation of available power between load and battery charging up to twice-rated output current
  • Visual indication of "power shortage","defective battery", "battery voltage< 30%", "battery charging level", self-diagnostic with flashing LED code
  • Warning relays: "main or back-up" and "defective/flat battery" with galvanic isolated output contacts NO-NC
  • 3 charging levels: "boost", "trickle" and "recovery"
  • Self-diagnosis "overload", "battery sulfutation", "reverse polarity connection", "elements in short circuit", "protection against short circuit"
  • Compatible with a remote connection to select "boost" or "trickle" charging mode
  • Accessories upon request: external temperature sensors; voltage drop compensation; remote LED display
  • Compact dimensions
  • Ambient temperature operation: -10 ÷ 50° C
  • IP 20
» Datasheets and Manuals Scarica File Allegati
Battery Bank





Main features:

  • Maintenance free lead AGM, VRLA Technology
  • Output: 24Vdc 1.2, 3, 7.2, 12Ah
  • Protection: Fuse
  • Connection with screws
  • Short Circuit Protection
  • IP20
  • Wall Mount with screws
  • DIN Rail Mount
  • Small Size on the panel





» Datasheets and Manuals Scarica File Allegati
Battery Bank






Main features:

  • Output voltage 27,5Vdc (20°C)
  • Short-circuit protection
  • Operating range in minutes
  • Small size
  • Ambient temperature operation field: 5 ÷ 40°C
  • IP20
» Datasheets and Manuals Scarica File Allegati
Charge&Testing




Battery charger with built-in intelligence



CB12245AJ is a charging and testing unit with an integrated CANbus-communication functionality.

Thanks to our Battery-Care philosophy, this device optimizes its battery life. It is housed in strong enclosures and it is easy to install as it comes with an automatic coupling for DIN Rails. Once the batteries have been automatically charged, the CB chargers check the battery life status to avoid all risk of damage, thus allowing the device to remain permanently under load.

The CB12245AJ is based on the latest generation of microcontrollers and it covers more than 50 parameters regarding charging status and failure through the CANbus J1939 protocol. ADEL system battery chargers have four charging stages and provide an accurate battery diagnosis. These devices are considered a revolution in the High-Tech application of energy management.

  • Extremely Small Size

  • Automatic four stage-charging profiles

  • Fast-loading technology

  • Power Supply function

  • Batteries able to be charged with temperature compensation

  • Straightforward diagnostic and monitoring of battery and device

  • Maximum safety and protection through standard features

  • UL Approved (pending)

  • IP protection 20

  • Loading and monitoring of all battery types (AGM, Gel, Ni-Cd, Ni-MH, Li-Ion)

  • Automatic “de-rating” to comply with strong fields

Insight




Remote Controller

CANbus J1939 allows the remote monitoring of more than 50 parameters regarding battery charging and charger status.

Battery Charger

Multistage battery charger that works on all battery types. Recovery, boost, absorption and float. Recharge batteries that are close to zero. Customizable charging curves.

Battery Tester

Battery care is our main philosophy. The battery chargers monitor reverse polarity, battery connection, short circuit, overload and charge current limit.



Benefits



  • CAN Connection J1939 covers more than 50 parameters
  • One device for all battery types: Lead Acid, AGM, Gel, Ni-Cd, Li-Ion
  • Multistage Charging. Four Charging Modes: Recovery, Boost, Absorption, Float
  • Adjustable charging current
  • Selectable Fast-Charge option
  • Testing Battery: Reverse Polarity, Disconnected Battery, Short Circuit, Opened Element, Close-to-Zero Battery
  • Wide input voltage range: 115-230-277 Vac
  • One single device for 12-or 24-VDC-Output
  • Power Supply Function
  • Fail Contact Alarm
  • LED Diagnosis Alarm
  • Suitable for DPY351








Generator Sets ,Gen set, Engine Starting, Industrial Fire Protection  Systems Water Pumping





» Datasheets and Manuals Scarica File Allegati
Industrial Power Supply





Main features:

  • Competitive price/performances ratio.
  • 3 protective functions: Hiccup Mode, Fold Back, Restart after Main
  • Declared ambient temperature operations field: 40,50 e 60°C (suitable for any type of applications)
  • Only one product for 230-400-500 Vac
  • Standards Conformity: EN 60204-1 and EN/IEC 60529 (IP20 protection class)
  • DIN Rail Mounting
  • Extremely small size

The 3 protective functions:

  • Hiccup Mode (Default)
  • Fold Back (Continuous Output Mode)
  • Restart after Main (Manual Reset)

Output Voltage:

  • 5; 12; 24; 48 Vdc

Output Direct Current:

  • 1-phase: 2 – 2,5 –5 - 7,5 – 9 -14,5 –25A
  • 2-phase: 5 –7,5 –14,5A
  • 3-phase: 25A

» Datasheets and Manuals Scarica File Allegati
Industrial Power Supply

Main Features:

  • For industrial and domestic applications
  • Wide input range: 100-240 Vac
  • Range product from 15 to 60 W
  • Protection class II
  • Wide temperature range: -25 to +70°C
  • Continuous Mode protection for Overload and short-circuit
  • DIN Rail and wall mount; Automatic Snap on
  • Extremely small size, more efficiency
  • 3 years warranty

Output Voltage:

  • 12;24 Vdc

Output Direct Current:

  • 1 phase: 0.6 - 2 - 2.8 A





  •
» Datasheets and Manuals Scarica File Allegati
Industrial Power Supply




Main features:

  • Input rated voltage: 24 Vac, 24 Vdc, 48 Vdc
  • Output: 5 - 12 - 24 Vdc
  • Output In: 3 - 5 - 7 A
  • Non-adjustable output
  • Extremely compact dimensions
  • Ambient temperature operation field: 0 - 50° C



» Datasheets and Manuals Scarica File Allegati
Industrial Power Supply



Main features:

  • Input rated voltage: 24 Vac, 24 Vdc, 48 Vdc
  • Output: 5 - 12 - 24 Vdc
  • Output In: 0,8 ÷ 20 A
  • Adjustable output ± 10% ±90%
  • Extremely compact dimensions
  • Ambient temperature operation field: 0 - 50° C



» Datasheets and Manuals Scarica File Allegati
DC/DC Converters

Caratteristiche principali:

  • Tensione di uscita: 24Vdc
  • Corrente di uscita: 1,3 ÷ 10A
  • Uscita regolabile ± 10%
  • Dimensioni estremamente compatte
  • Intervallo di temperatura 0 - 50°C

La gamma SUP comprende alimentatori/convertitori con isolamento galvanico tra primario e secondario, basati sulla tecnologia switching, il cui range di ingresso può variare da 18 a 36Vdc, mantenendo stabile la tensione di uscita a 24Vdc, per fino a 10 A.
Predisposti per fissaggio a pannello, oppure tramite accessorio, anche a Barra DIN. Sono protetti al cortocircuito e al sovraccarico in uscita.

» Datasheets and Manuals Scarica File Allegati
DC/DC Converters

Main features:

  • Input: 12 Vdc
  • Output: 24 - 30 - 40 - 48 - 60 Vdc
  • Output In: 3 A ÷ 6 A
  • Adjustable output ±10%
  • Ambient temperature operation field: 0 - 50° C
  • IP20

The low voltage power supplies/converters in the STEP-UP range are suitable for producing voltages higher than the input voltage. They are typically used for currents of 3-6A, in cases where there is a rated input voltage of 12Vdc transformed into higher output voltage, perhaps to connect to a 12Vdc battery to then power a 24Vdc PLC. STEP-UP units feature switch-mode technology, are DIN Rail Mountable, and have output short-circuit and overload protection. For use in industrial and automotive applications, they are particularly reliable, robust, easy to use and comply with the latest regulatory standards.
