Monitor, Configure, Connect



The DPY351 is a robust and versatile multifunction display that allows monitoring, configuring and managing the ADELSystem devices connected in an ADELBus network.



It is equipped with a high-brightness and wide viewing-angle 3.5’’ TFT screen which guarantees an optimum visibility in any operating condition.    Intuitive Human-Machine Interface (HMI) is a user interface or dashboard clear and intuitive Ethernet interface inside, allows to configure and managing true ADELBus the devices connected through its,  by using the SNMP and Modbus TCP protocols.    It is possible to connect several devices in chain together, up to 50.



Monitoring  It is possible the monitoring of the input and output data, peak current, peak voltage, all the battery parameters such as temperature, State of Charge internal Impendency  Configuration  With the DPY351, it is possible to modify the parameters of any ADELsystem device connected: DC Ups, Power Supply and Battery Charger. Alarms management All the alarms present on the single device are immediately reported.  History The history parameters are recorded inside each device. The DPY351 allows inspecting all the historical parameters of each single device. Logging  The device memorize and display the last 20 action done. Web Server  It is possible configure and drive the device by Own Server Event Actions that are coordinated among the devices connected can be programmed, thus automating the system.



So many way to use and apply it


Monitor and Control To monitor all the parameters of installed devices in the panel	Comunication Essential to transfer all parameters remotely via Ethernet connection	All in One It includes 2 Input 1 Output and a temperature sensor that allows sensor management in small environments. All in one: Display, Hub, PLC

Display parameters as you prefer

Display Configuration

Display Configuration “Homepage”

Customize Dashboard






Customize “Six Values”	Customize “Six Values”
Customize “Two Values”	Customize “Single Value"

Add new device

Notification Alarm

Gateway and Protocolli

Web Server HTTP for Configuration and Driver the device by Ethernet; static or Dynamic IP

Modbus TCP/IP Configuration TCP/IP Configuration group of parameter default values. They allow unique identification of the unit in the network.

SNMP v2c An ADELsystem MIB table is provided which consists of a list of parameters of the connected power device that can be remotely read, or read-written through the SNMP. Each parameter, (OID), is mapped one-to-one to a Modbus RTU holding register.

MQTTMQTT communication allows the DPY351 to connect to the ADELView System Cloud for the remote monitoring of the power devices connected to the DPY using Modbus or CANbus

Connection & Control

DPY351 was developed to connect to all the new devices developed by ADELSystem. Through ADELBus (CANBus and ModBus) it is possible to establish the connection of configuration, reading, evolution of the device data. Through the DPY351 it is possible to create Events, they are the result of an algorithm established by the DPY351 among the various interconnected devices.

Main features

• Output current 2,5 A ÷ 20 A even in case of power outage (shortage)
• Automatic allocation of available power between load and battery charging up to twice-rated output current
• Visual indication of "power shortage","defective battery", "battery voltage< 30%", "battery charging level", self-diagnostic with flashing LED code
• Warning relays: "main or back-up" and "defective/flat battery" with galvanic isolated output contacts NO-NC
• 3 charging levels: "boost", "trickle" and "recovery"
• Self-diagnosis "overload", "battery sulfutation", "reverse polarity connection", "elements in short circuit", "protection against short circuit"
• Compatible with a remote connection to select "boost" or "trickle" charging mode
• Accessories upon request: external temperature sensors; voltage drop compensation; remote LED display
• Compact dimensions
• Ambient temperature operation: -10 ÷ 50° C
• IP 20

Main features:

• Ambient temperature operation field: -25 ÷ 60°C
• IP20
• DIN Rail Mounting
• Extremely small size
• Current reserve

Output Voltage:
– PSM 1-phase: 5 – 12 - 24 - 48Vdc
- PSM 2-phase: 24Vdc

Output Direct Current:
– PSM 1-phase: 1,5 – 2,5 – 5 - 7- 10A

Main features:

• Maintenance free lead AGM, VRLA Technology
• Output: 24Vdc 1.2, 3, 7.2, 12Ah
• Protection: Fuse
• Connection with screws
• Short Circuit Protection
• IP20
• Wall Mount with screws
• DIN Rail Mount
• Small Size on the panel

Main features:

• Output voltage 27,5Vdc (20°C)
• Short-circuit protection
• Operating range in minutes
• Small size
• Ambient temperature operation field: 5 ÷ 40°C
• IP20

Main features:

• Competitive price/performances ratio.
• 3 protective functions: Hiccup Mode, Fold Back, Restart after Main
• Declared ambient temperature operations field: 40,50 e 60°C (suitable for any type of applications)
• Only one product for 230-400-500 Vac
• Standards Conformity: EN 60204-1 and EN/IEC 60529 (IP20 protection class)
• DIN Rail Mounting
• Extremely small size

The 3 protective functions:

• Hiccup Mode (Default)
• Fold Back (Continuous Output Mode)
• Restart after Main (Manual Reset)

Output Voltage:

• 5; 12; 24; 48 Vdc

Output Direct Current:

• 1-phase: 2 – 2,5 –5 - 7,5 – 9 -14,5 –25A
• 2-phase: 5 –7,5 –14,5A
• 3-phase: 25A

Main Features:

• For industrial and domestic applications
• Wide input range: 100-240 Vac
• Range product from 15 to 60 W
• Protection class II
• Wide temperature range: -25 to +70°C
• Continuous Mode protection for Overload and short-circuit
• DIN Rail and wall mount; Automatic Snap on
• Extremely small size, more efficiency
• 3 years warranty

Output Voltage:

• 12;24 Vdc

Output Direct Current:

• 1 phase: 0.6 - 2 - 2.8 A

Main features:

• Input rated voltage: 24 Vac, 24 Vdc, 48 Vdc
• Output: 5 - 12 - 24 Vdc
• Output In: 3 - 5 - 7 A
• Non-adjustable output
• Extremely compact dimensions
• Ambient temperature operation field: 0 - 50° C

Main features:

• Input rated voltage: 24 Vac, 24 Vdc, 48 Vdc
• Output: 5 - 12 - 24 Vdc
• Output In: 0,8 ÷ 20 A
• Adjustable output ± 10% ±90%
• Extremely compact dimensions
• Ambient temperature operation field: 0 - 50° C

Main features

• Ambient temperature operation field: -25 ÷ 60°C
• IP20
• DIN Rail Mounting
• Extremely small size
• Current reserve

Output Voltage:

- PST 3-phase: 24 - 48Vdc

Output Direct Current:

- PST 3-phase: 40A

Caratteristiche principali:

• Tensione di uscita: 24Vdc
• Corrente di uscita: 1,3 ÷ 10A
• Uscita regolabile ± 10%
• Dimensioni estremamente compatte
• Intervallo di temperatura 0 - 50°C

La gamma SUP comprende alimentatori/convertitori con isolamento galvanico tra primario e secondario, basati sulla tecnologia switching, il cui range di ingresso può variare da 18 a 36Vdc, mantenendo stabile la tensione di uscita a 24Vdc, per fino a 10 A.
Predisposti per fissaggio a pannello, oppure tramite accessorio, anche a Barra DIN. Sono protetti al cortocircuito e al sovraccarico in uscita.

Main features:

• Input: 12 Vdc
• Output: 24 - 30 - 40 - 48 - 60 Vdc
• Output In: 3 A ÷ 6 A
• Adjustable output ±10%
• Ambient temperature operation field: 0 - 50° C
• IP20

The low voltage power supplies/converters in the STEP-UP range are suitable for producing voltages higher than the input voltage. They are typically used for currents of 3-6A, in cases where there is a rated input voltage of 12Vdc transformed into higher output voltage, perhaps to connect to a 12Vdc battery to then power a 24Vdc PLC. STEP-UP units feature switch-mode technology, are DIN Rail Mountable, and have output short-circuit and overload protection. For use in industrial and automotive applications, they are particularly reliable, robust, easy to use and comply with the latest regulatory standards.
