Monitor, Configure, Connect



The DPY351 is a robust and versatile multifunction display that allows monitoring, configuring and managing the ADELSystem devices connected in an ADELBus network.



It is equipped with a high-brightness and wide viewing-angle 3.5’’ TFT screen which guarantees an optimum visibility in any operating condition.    Intuitive Human-Machine Interface (HMI) is a user interface or dashboard clear and intuitive Ethernet interface inside, allows to configure and managing true ADELBus the devices connected through its,  by using the SNMP and Modbus TCP protocols.    It is possible to connect several devices in chain together, up to 30.



Monitoring  It is possible the monitoring of the input and output data, peak current, peak voltage, all the battery parameters such as temperature, State of Charge internal Impendency  Configuration  With the DPY351, it is possible to modify the parameters of any ADELsystem device connected: DC Ups, Power Supply and Battery Charger. Alarms management All the alarms present on the single device are immediately reported.  History The history parameters are recorded inside each device. The DPY351 allows inspecting all the historical parameters of each single device. Logging  The device memorize and display the last 20 action done. Web Server  It is possible configure and drive the device by Own Server Event Actions that are coordinated among the devices connected can be programmed, thus automating the system.



So many way to use and apply it


Monitor and Control To monitor all the parameters of installed devices in the panel	Comunication Essential to transfer all parameters remotely via Ethernet connection	All in One It includes 2 Input 1 Output and a temperature sensor that allows sensor management in small environments. All in one: Display, Hub, PLC

Display parameters as you prefer

Display Configuration

Display Configuration “Homepage”

Customize Dashboard






Customize “Six Values”	Customize “Six Values”
Customize “Two Values”	Customize “Single Value"

Add new device

Notification Alarm

Gateway and Protocolli

Web Server HTTP for Configuration and Driver the device by Ethernet; static or Dynamic IP

Modbus TCP/IP Configuration TCP/IP Configuration group of parameter default values. They allow unique identification of the unit in the network.

SNMP v2c An ADELsystem MIB table is provided which consists of a list of parameters of the connected power device that can be remotely read, or read-written through the SNMP. Each parameter, (OID), is mapped one-to-one to a Modbus RTU holding register.

MQTTMQTT communication allows the DPY351 to connect to the ADELView System Cloud for the remote monitoring of the power devices connected to the DPY using Modbus or CANbus

Connection & Control

DPY351 was developed to connect to all the new devices developed by ADELSystem. Through ADELBus (CANBus and ModBus) it is possible to establish the connection of configuration, reading, evolution of the device data. Through the DPY351 it is possible to create Events, they are the result of an algorithm established by the DPY351 among the various interconnected devices.

Battery charger with built-in intelligence

CB12245AJ is a charging and testing unit with an integrated CANbus-communication functionality.

Thanks to our Battery-Care philosophy, this device optimizes its battery life. It is housed in strong enclosures and it is easy to install as it comes with an automatic coupling for DIN Rails. Once the batteries have been automatically charged, the CB chargers check the battery life status to avoid all risk of damage, thus allowing the device to remain permanently under load.

The CB12245AJ is based on the latest generation of microcontrollers and it covers more than 50 parameters regarding charging status and failure through the CANbus J1939 protocol. ADEL system battery chargers have four charging stages and provide an accurate battery diagnosis. These devices are considered a revolution in the High-Tech application of energy management.

Extremely Small Size Automatic four stage-charging profiles Fast-loading technology Power Supply function Batteries able to be charged with temperature compensation Straightforward diagnostic and monitoring of battery and device Maximum safety and protection through standard features UL Approved (pending) IP protection 20 Loading and monitoring of all battery types (AGM, Gel, Ni-Cd, Ni-MH, Li-Ion) Automatic “de-rating” to comply with strong fields

Insight

Remote Controller CANbus J1939 allows the remote monitoring of more than 50 parameters regarding battery charging and charger status. Battery Charger Multistage battery charger that works on all battery types. Recovery, boost, absorption and float. Recharge batteries that are close to zero. Customizable charging curves. Battery Tester Battery care is our main philosophy. The battery chargers monitor reverse polarity, battery connection, short circuit, overload and charge current limit.   Benefits   CAN Connection J1939 covers more than 50 parameters One device for all battery types: Lead Acid, AGM, Gel, Ni-Cd, Li-Ion Multistage Charging. Four Charging Modes: Recovery, Boost, Absorption, Float Adjustable charging current Selectable Fast-Charge option Testing Battery: Reverse Polarity, Disconnected Battery, Short Circuit, Opened Element, Close-to-Zero Battery Wide input voltage range: 115-230-277 Vac One single device for 12-or 24-VDC-Output Power Supply Function Fail Contact Alarm LED Diagnosis Alarm Suitable for DPY351



Generator Sets ,Gen set, Engine Starting, Industrial	Fire Protection  Systems	Water Pumping



Caratteristiche principali:

• Tensione di uscita: 24Vdc
• Corrente di uscita: 1,3 ÷ 10A
• Uscita regolabile ± 10%
• Dimensioni estremamente compatte
• Intervallo di temperatura 0 - 50°C

La gamma SUP comprende alimentatori/convertitori con isolamento galvanico tra primario e secondario, basati sulla tecnologia switching, il cui range di ingresso può variare da 18 a 36Vdc, mantenendo stabile la tensione di uscita a 24Vdc, per fino a 10 A.
Predisposti per fissaggio a pannello, oppure tramite accessorio, anche a Barra DIN. Sono protetti al cortocircuito e al sovraccarico in uscita.
